Manufacturer:Allen-Bradley

Model Number:1756-CN2RXT

Network Compatibility:ControlNet

Redundancy:Redundant

Number of Channels:2

Current Rating (Drawn):970 mA at 5.1 VDC, 1.7 mA at 24 VDC

Isolation:30 V (Continuous)

Basic Insulation Type:

Communication Type:ControlNet A/B to Backplane, ControlNet A to ControlNet B

Enclosure Type:Open Type

RFI Suppression:Radiated: 10 V/M with 1 KHZ Sine-Wave 80% AM from 80 – 2000 MHz, 10 V/M with 200 Hz 50% Pulse 100% AM at 900 MHz, 10 V/M with 200 Hz 50% Pulse 100% AM at 1890 MHz, 3 V/M with 1 KHZ Sine-Wave 80% AM from 2000 – 2700 MHz

Temperature Rating:Operational within 32 – 140 °F (-20 – 60 °C)

    Engineered for reliability and efficiency, the AB 1756-CN2RXT is designed to withstand harsh industrial environments while ensuring uninterrupted data flow between control systems and peripheral devices.

    This module supports dual redundant communication paths, enhancing system availability and reducing the risk of downtime caused by single point failures.

    Utilizing advanced isolation technology, it ensures robust electrical separation, protecting against electromagnetic interference and ensuring secure data transmission.

    With its open-type enclosure, the AB 1756-CN2RXT is suitable for various mounting scenarios, offering flexibility in integration with existing infrastructure.

    Backed by Allen-Bradley’s commitment to quality and support, this module comes with comprehensive documentation and access to extensive training resources, facilitating easy installation and maintenance.
