3BSE038415R1 – ABB Module

Product Type:Analog Output Module

Model:AO810V2

Sub-Model:3BSE038415R1

Number of Channels:8

Channel Configuration:Dual-Ended

Supply Voltage:DC 24V

Current Capacity:Max. 20mA per channel

Output Type:0…10V DC

Isolation Voltage:500V AC

Operating Temperature:-25°C to +60°C

Storage Temperature:-40°C to +85°C

Mounting Type:Panel-Mount

Dimensions (WxHxD):95 x 95 x 30mm

Weight:Approx. 0.1kg

    Precision engineered for industrial automation, the ABB AO810V2 3BSE038415R1 Analog Output Module ensures reliable performance in a wide range of applications.

    Each of the 8 channels is equipped with dual-ended output capabilities, allowing for versatile connection options to match diverse industrial requirements.

    With a maximum current capacity of 20mA per channel, this module provides ample power for driving various actuators or sensors, ensuring efficient operation.

    Featuring a robust DC 24V supply voltage, the module supports a wide variety of control systems, making it a flexible choice for integration into existing setups.

    Equipped with a 500V AC isolation voltage, the AO810V2 guarantees safe operation in environments with potential electrical hazards, enhancing system reliability.

    Operating within a temperature range from -25°C to +60°C and capable of storage at temperatures up to +85°C, this module is designed for harsh industrial conditions, ensuring consistent performance throughout its lifecycle.
