Brand:HEIDENHAIN
Model:ROD700-18000
Resolution:1 micron
Measuring Length:18000 mm
Accuracy Class:±1 µm/m
Signal Period:20 µm
Operating Temperature Range:-50 to +120 °C
Interface:Incremental, EnDat 2.2
Protection Rating:IP67
The HEIDENHAIN ROD700-18000 Linear Encoder System is designed for demanding industrial environments where precision and reliability are paramount. This system provides ultra-high accuracy with a resolution down to 1 nanometer, making it ideal for applications requiring extremely fine position control. Its measuring length of up to 18 meters allows for extensive travel distances, while maintaining high accuracy over the entire range.
The system uses the advanced EnDat 2.2 interface, ensuring reliable communication and data transfer between the encoder and the control system. It is equipped with robust materials designed to withstand harsh conditions, including temperatures ranging from -50°C to +120°C and protection ratings up to IP67.
Installation is straightforward, thanks to its compact design and user-friendly interface. The system’s compatibility with standard industrial protocols makes it easy to integrate into existing systems without requiring significant modifications or additional components. The HEIDENHAIN ROD700-18000 Linear Encoder System is CE and RoHS certified, ensuring compliance with international safety and environmental standards.
