National Instruments PCI-6224 Analog Inputs Module, High-Resolution Data Acquisition, Industrial Control Solutions

Data Rate:50 kS/s per channel

Resolution:14-bit

Channels:16 channels

Input Range:-10V to +10V

Sampling Frequency:Up to 250 kS/s

Accuracy:±0.02% + ±2 LSBs

Temperature Operation Range:-40°C to +85°C

Power Consumption:≤ 5 W

Interface:PCI Express

    The National Instruments PCI-6224 Analog Input Module is a compact solution for acquiring and processing analog signals in real-time, ideal for applications requiring high precision and speed. It boasts an impressive 16-channel design, capable of operating within a wide voltage range from 0 to 5V or 0 to 10V, ensuring compatibility across various industrial environments.

    With a sampling rate of up to 1 Ms/s, this module excels in capturing rapid changes in signal, making it suitable for applications in fields such as automotive testing, medical equipment monitoring, and environmental studies where high-speed data acquisition is crucial.

    Featuring a 12-bit resolution, the PCI-6224 ensures exceptional accuracy in its measurements, which is critical for applications that demand precise data analysis. The PCIe x1 interface provides a reliable connection to modern computing systems, facilitating seamless integration into existing setups.

    Designed for robust operation, this module is rated to withstand temperatures ranging from -40°C to 85°C during operation and from -55°C to 105°C when stored. This wide temperature range allows for deployment in a variety of challenging environments without compromising performance.

    Additionally, the PCI-6224 Analog Input Module comes equipped with efficient power management, consuming a maximum of 2.2W, which not only saves energy but also ensures reliable operation even in power-sensitive applications. Its compact size and comprehensive feature set make it a versatile choice for integrating into complex systems where space is a concern.
