S – Schneider LC1-D170 AC Contactor, Schneider

Type:AC Contactor

Brand:Schneider

Model Number:LC1-D170

Number of Poles:3P

Contact Composition:3 NO

Rated Current:170A

Operating Voltage Range:AC 25…400 Hz, <= 690 V

Control Circuit Voltage:24 V DC

Inrush Current Limiting:Yes

Insulation Class:H

Enclosure Rating:IP20

Weight:Approx. 0.3 kg

Dimensions:125mm x 85mm x 78mm

Switching Capacity:Up to 690 V AC, 6 A at 24 V DC

Operational Life:Over 10 million operations

    The Schneider LC1-D170 AC contactor is part of the LC1 series, renowned for its reliability and robustness in harsh industrial environments. It offers exceptional performance in controlling AC motors and loads, providing a solid foundation for efficient and stable operations.

    Featuring a high-power rating of 170A, it ensures reliable control over a wide range of industrial equipment. Its AC-3 electrical rating at 690V 50/60Hz supports versatile use across different applications.

    With 3NO contacts, the contactor is designed for precise switching actions, delivering high-quality performance and minimizing downtime. The inclusion of an insulation level of Class I adds to its safety and reliability in various industrial settings.

    Equipped with a 24V DC control circuit voltage, the Schneider LC1-D170 is compatible with modern control systems, making it easy to integrate into existing automation solutions. Its switching frequency of 2500 cycles per hour demonstrates its capability to handle frequent start-stop operations.

    This contactor boasts a life expectancy of 300,000 operations, ensuring long-lasting performance even under demanding conditions. The operating temperature range of -25°C to +50°C and storage temperature range of -40°C to +70°C make it suitable for a wide array of industrial locations.
