ES7972 – Siemens connector

Model Type:DP Bus Connector

Model Number:6ES7972-0BA60-0XA0

Manufacturer:SIEMENS

Estimated Shipping Size Dimension:7.10 x 7.90 x 3.00 inches

Weight:0.042 kg

Technology:IPCD Technology Fast Connect

Connection Angle:35 Degree

Cable Outlet Dimensions:15.8 x 54 x 39.5 mm (WXHXD)

Socket Type:Without PG Socket

Data Rate:Up to 12 Mbps

Module Class:HMI Simatic

Isolation Function:Yes

Application:Industrial Automation Systems

    The SIEMENS 6ES7972-0BA60-0XA0 Profibus DP Bus Connector is designed for high-speed data exchange in industrial automation environments. Its compact yet robust design ensures reliable operation in challenging conditions, making it an indispensable component for modern manufacturing systems.

    With its 35-degree angled cable outlet, the connector provides an ergonomic solution for cable management, enhancing both safety and efficiency on the factory floor. The IPCD Technology Fast Connect feature facilitates quick and secure installation, reducing downtime and maintenance costs.

    Engineered with precision, this connector supports Profibus data transfer rates up to 12 Mbit/s, ensuring fast and accurate communication between different devices within the network. It’s compatible with various Siemens automation products, including PLCs and HMIs, fostering seamless integration and scalability.

    The inclusion of IP protection ensures the connector is suitable for industrial environments with dust, moisture, and temperature variations. This makes it ideal for applications in diverse sectors such as automotive, food & beverage, and pharmaceutical industries, where reliability and performance are paramount.

    The absence of a PG socket simplifies the connection process and reduces the risk of errors during installation. This streamlined approach contributes to enhanced productivity and operational efficiency, aligning with the ongoing digital transformation in industry 4.0.
